Technical Specifications
Parameters
|
Characteristics
|
Product
|
In-Cable Control- and Protection Device (IC-CPD) Portable EV AC Type2 Car Charger
|
Rated Power
|
3.3kW
|
Number of Output
|
1
|
Output Current Range
|
0-16A
|
Input Voltage
|
100-265V
|
Output Charging Outlet
|
IEC62196 Type2
|
Output voltage
|
230Vac
|
Operating Temperature
|
-20°C to 55°C
|
Storage Temperature
|
-40°C to 85°C
|
Altitude
|
<2000 Mtr
|
Humidity
|
<95%, Non condensing
|
Charging Operation
|
Plug & Play
|
Mechanical Protection
|
IP67
|
Cooling
|
Natural Cooling
|
Impact Insertion Force
|
>300N
|
Mating Cycles
|
>10000
|
Contact Pin
|
Copper Alloy, Silver
|
Overvoltage Protection
|
Yes
|
Short-circuit Protection
|
Yes
|
Overcurrent Protection
|
Yes
|
Surge Protection
|
Yes upto 8kV
|
Relay Welding Protection
|
Yes
|
Enclosure Dimensions
|
258 x 93 x 53 mm
|
Flame Retardant Grade Enclosure
|
UL94 V-0
|
Connector Type
|
IEC62196 Type2 (with Temp sensor)
|
Gun Side Cable Nominal Conductor Size (Sq. mm)
|
3core*2.5 sq mm + 2core*0.5 sq mm + 2core*0.35 sq mm (Temp sensor)
|
Gun Side Cable Length
|
5 Meters
|
Plug Side Cable Cable Outer Sheathing
|
TPE/TPU (FR)
|
Plug Side Cable Length
|
T0.6 Meter
|
